40G QSFP+ Active Optical Cables

1. Applications

Ø Low-latency and high-speed interconnections for high performance computing(HPC)

Ø 40G Ethernet SR4

Ø Other high-throughput data transmission network

Ø Storage area Network(SAN)

2. Features

Ø Quad Small Form-factor Pluggable (QSFP)

Ø 40GBASE-SR4 compliant

Ø QDR, DDR, SDR (Infiniband) compliant

Ø Bi-directional parallel link

Ø 10.3125Gb/s per lane, x4 channels

Ø Up to 100m

Ø Low profile connectors

Ø Low power consumption

Ø Bundle multi-mode fiber array

Ø 850nm VCSEL four array

Ø PIN diode four array

Ø Hot-Pluggable

Ø I2C management interface

Ø From 0 to 70 degree case temperature

Ø 3.3V power supply voltage

Ø Electrical 38-pin connector

3. Description

Handar's HD-QSFP+/40G-AOC series are active optical cables (AOC) that allows bi-directional 40Gbps transmission suitable for Ethernet 40GBASE-SR4 and Infini Band QDR application and other high-throughput data network, with advantages such as high speed, high density, low latency, low power consumption and light weight.
